30kw 650kg School Large Diesel Generator With Three Cylinder Engine

Product Categories

Weifang Best Power Equipment Co., Ltd.

Contact Now

30kw 650kg School Large Diesel Generator With Three Cylinder Engine

Name: 30kw 650kg School Large Diesel Generator With Three Cylinder Engine
Brand: BST-WEICHAI
Price: 1 USD

China 30kw 650kg School Large Diesel Generator With Three Cylinder Engine factory

Brand Name : BST-WEICHAI

Model Number : D226B-3D

Certification : CE ISO

Place of Origin : Weifang

MOQ : 1

Price : Negotiated Price

Supply Ability : 100Set per month

Packaging Details : Plastic/ Wooden Case Packing Or Customized

Delivery Time : 30 work days

Speed : 1500/1800RPM

Rated Power : 30Kw

Rated Current : 54A

Frequnecy : 50/60Hz

Rated Voltage : 400/230V

Output Type : AC Three Phase

Genset Weight(kg) : 650Kg

Dimension(mm) : 1650*700*1120

Number of Cylinder : 3

Cooling System : Water-cooled

Cycle : Four Stroke

Contact Now

Technical data
Genset Model	BST-30GF
Prime Power	30KW/37.5KVA
Rated Voltage	400/230V
Frequency	50/60Hz
Power Factor	0.8(lagging)
The regulating rate of steady voltage	≤±0.5%
The regulating rate of instantaneous voltage	≤-15%/ +20%
The time of steady voltage	≤1.5sec
The waving rate of voltage	≤1.0%
The regulating rate of steady frequency	≤3%
The regulating rate of instantaneous frequency	≤±10%
The time of steady frequency	3sec
Dimension (L×W×H) (mm)	16507001120
Genset weight (kg)	650
Diesel Engine
Brand	Weichai
Model	D226B-3D
Number of Cylinders	3
Rotating Speed	1500/1800RPM
Cycle	Four stroke
Type	waste gas turbine boost,direct spurting type
Bore×Stroke(mm)	100*115
Displacement(L)	3.6
Lubricating Capacity(L)	10
Speed Governor	Electrical
Cooling System	Water-cooled
Speed Stability (%)	≤5%
Fuel Consumption at 100% Load	236g/kw.h
Starting Method	DC24V Electrical starting
Alternator
Brand	Stamford
Model	30GF
Number of Phase	3
Connecting Type	Three Phase and Four Lines
Number of Bearing	1
Grading Protection	IP22
Altitude	≤1000m
Exciter Type	Brushless (AVR automatic voltage regulating)
Insulation Class	H degree

30kw 650kg School Large Diesel Generator With Three Cylinder Engine
Certificate Show:

Our service :

1. Help Customers find out the suitable power of the diesel generator.
2. Show the detail specifications to customers to choosen.
3. Help customers figure out the freight and arrange it.

FAQ:
1. What is the minimum order quantity for your project ?
Our order quantity is 1 set .
2. What Is Your Delivery Time?
Less than 10sets, 15 working Days After Received The 30%T/T Deposit.
3. Can You Make Your Own Brand For Your Customers ?
We Can be Your OEM Manufacturer With Your Authorization Of Brand.
4. What Are Your Payment Terms?
30% TT As Deposit,70% TT Before Shipment.
5. What is your company's available production capacity?
We Can Provide 100 Sets Per Month.
6. What ls The Warranty Period For Your Diesel Generator?
Our Warranty Period: 12 Months Or 1000 Hours Of Work!
